Poly Ducted Laboratory Chemical Fume Hood / Cupboard with PP Cup Sink for testing, lab use

Thông tin chi tiết sản phẩm

Place of Origin: CHINA

Hàng hiệu: SOPERSL

Chứng nhận: ISO9001

Model Number: PFH6-1500

Điều khoản thanh toán & vận chuyển

Minimum Order Quantity: 5

Giá bán: Negotiation

Packaging Details: crate box

Delivery Time: 25-30 Days

Payment Terms: T/T or L/C at sight

Supply Ability: 1500 per month

Nhận giá tốt nhất
Làm nổi bật:

chemical fume extractor

,

exhaust fume hoods

Màu sắc:
màu trắng
Chức năng:
TRONG PHÒNG THÍ NGHIỆM
Vật liệu:
nhiều
vận tốc không khí:
0,5m/giây
Tiếng ồn dBA:
≤ 60
Máy thổi:
Tích hợp quạt ly tâm
chiếu sáng:
≥450Lux
cửa sổ sash:
Kính cường lực hai lớp 5mm
Cửa thoát khí:
Φ250mm
Màu sắc:
màu trắng
Chức năng:
TRONG PHÒNG THÍ NGHIỆM
Vật liệu:
nhiều
vận tốc không khí:
0,5m/giây
Tiếng ồn dBA:
≤ 60
Máy thổi:
Tích hợp quạt ly tâm
chiếu sáng:
≥450Lux
cửa sổ sash:
Kính cường lực hai lớp 5mm
Cửa thoát khí:
Φ250mm
Poly Ducted Laboratory Chemical Fume Hood / Cupboard with PP Cup Sink for testing, lab use

Polypropylene Ducted  Laboratory Chemical Fume Hood / Cupboard with PP Cup Sink



Production Description

  • 8mm.Polypropylene material
  • polypropylene, acid and alkali resistance, temperature- resistance, anti-moisture
  • Easy: install and wash.
  • strong bearing capacity

Name

Value

Brand

SOPERSL

Model

PFH6-150

Window

5mm PS transparent plate, balancing form elevation and subsidence, it can be stopped at any position by pulling.

Handles

PP handles.

Lighting equipment

40W*2 antisepsis daylight lamp, lamp house is insulated with gas.

Lightness on table not lower than 400LUX.

Operation panel

lighting switch, ON/OFF switch, two sets of 220V/10A versatile electric socket

Ventilation equipment

Selecting rust-resistance, low wasting, low noise and famous fan and special wind tube. Noise can be reduced at about 55 DB

Cubage

20L

Ext. sizes(H*W*D)

1500×850×2350mm

Operation table size(H*W*D)

1600×640×16mm

Accessory

Vertical and single test cock: made by brass, the surface is treated by EPOXY baking paint.

Cup slot: acid and alkali resistance, PP water cup.

Sink: PP cup sink.

Socket: multi-functional with splash-proof box and safeguard cover.

Warranty

One year

Application

PFH series Fume hoods are the first defense to minimize dangerous chemical exposure to research workers. They are considered the primary means of protection from inhalation of hazardous vapors.





Poly Ducted Laboratory Chemical Fume Hood / Cupboard with PP Cup Sink for testing, lab use 0Poly Ducted Laboratory Chemical Fume Hood / Cupboard with PP Cup Sink for testing, lab use 1



Description PFH6-120 PFH6-150 PFH6-180
Overall Size (With Base Cabinet) (H×W×D) 2400x1200x850mm 2400x1500x850mm 2400x1800x850mm
Working Area(H×W×D) 1100x1000x700mm 1100x1300x700mm 1100x1600x700mm
Base cabinet (H×W×D) 850 x1200x850mm
Work Platform Main Unit - 100%, 8 mm PP fabricated.
Construction Material Main Unit - 100%, 8 mm PP fabricated.
Window Made of 5mm tempered glass, max:820mm opening
Power supply
Touch control panel
AC220V10A ON/OFF Switches on front fascia (BL / FL) A fluorescent lamp, fan, the power switch and stand-by switch
Air Flow 100 % Air take from inside room through
Remote control water valve Pure water, tap-water
Remote control air valve One N2 valve, one vacuum valve
Water Tank One
Options and Accessories:

A wide range of configurations to suit any containment application: -

Base Cabinet with chemical storage cabinet (with air vent) (

Sink : Molded polypropylene sink with drain nipple

Auxiliary Socket – 5/15 Amp. – As require qty.

Filter chocking alarms , Universal Casters with Brake

OTHER CAPACITY : ON REQUEST
